Frappé Charts

GitHub-inspired modern, intuitive and responsive charts with zero dependencies

Explore Demos »

Contents

• Installation
• Usage
• Updates
• License

Installation

• Install via npm:

  $ npm install frappe-charts


  and include in your project:

  import Chart from "frappe-charts/dist/frappe-charts.min.esm"


• ...or include within your HTML

    <script src="https://unpkg.com/frappe-charts@0.0.7/dist/frappe-charts.min.iife.js"></script>


Usage

const data = {
    labels: ["12am-3am", "3am-6pm", "6am-9am", "9am-12am",
        "12pm-3pm", "3pm-6pm", "6pm-9pm", "9am-12am"
    ],
    datasets: [
        {
            title: "Some Data",
            values: [25, 40, 30, 35, 8, 52, 17, -4]
        },
        {
            title: "Another Set",
            values: [25, 50, -10, 15, 18, 32, 27, 14]
        }
    ]
}

const chart = new Chart({
    parent: "#chart", // or a DOM element
    title: "My Awesome Chart",
    data: data,
    type: 'bar', // or 'line', 'scatter', 'pie', 'percentage'
    height: 250,

    colors: ['#7cd6fd', '#743ee2'],

    format_tooltip_x: d => (d + '').toUpperCase(),
    format_tooltip_y: d => d + ' pts'
})

If you want to contribute:

1. Clone this repo.
2. cd into project directory
3. npm install
4. npm run dev

Updates

v0.0.7

• Custom color values for charts as hex codes. The API now takes an array of colors for all charts instead of a color for each dataset.
• @iamkdev's blog on usage with Angular.

v0.0.5

• More flexible Y values: independent from exponent, minimum Y axis point for line graphs.
• Customisable Heatmap colors; check out the Halloween demo on the website :D
• Tooltip values can be formatted.

v0.0.4

• Build update: Shipped an ES6 module, along with the browser friendly IIFE.

v0.0.2

• We have an animated Pie Chart! Thanks @sheweichun.
• @tobiaslins contributed tweaks for his quest to make these easy to use with React. Check out his repo and updates at #24 to learn more :)
• A new logo.

v0.0.1

• The very first version out, with animatable bars and lines, a percentage chart and a heatmap. GitHub-style.

License

This repository has been released under the MIT License

---

Project maintained by Frappe. Used in ERPNext. Read the blog post.
